Wheel Alignment Turn Plates with Brass Finish Dial, 4 Ton Capacity, and Bonus Accessories (Pair)
Wheel Alignment Turn Plates with Brass Finish Dial, 4 Ton Capacity, and Bonus Accessories (Pair)
Turn plates for wheel alignment.
DIY-friendly turn tables in two profiles. Roll onto them in your home garage and dial in camber and caster yourself.
Built for repeatable results.
Pick a model and hover or tap each point to see how it's built.
0.8" Ultra-Low, Drive-On
Sits low enough to drive onto directly on flat floors. Pair with our ASRP004 ramp level kit for an even smoother transition.
0.8" Ultra-Low, Drive-On
Sits low enough to drive onto directly on flat floors. Pair with our ASRP004 ramp level kit for an even smoother transition.
1.9" Raised, Pit Rack Ready
Drops into pit racks and raised platforms for garages that already have the clearance.
1.9" Raised, Pit Rack Ready
Drops into pit racks and raised platforms for garages that already have the clearance.
Pick the profile for your garage.
Same 4-ton capacity, same brass dial, same 1" offset. The only difference is installation height.
Ultra-Low Profile. Direct Drive-On.
At just 0.8" tall, the ASWG004 drives on flat floors directly. Pair with our ASRP004 ramp level kit for an even smoother transition. Ideal for classic builds, lowered cars, and tight-clearance vehicles.
Raised Profile. Pit Rack & Ramp.
The ASWG008 stands 1.9" tall, built to drop into pit racks and raised platforms where you already have elevated clearance.
ASWG004 vs ASWG008 side by side.
See how both profiles compare and pick the one that fits your garage.
Why AutoSolo turn plates.
Die-cast metal, brass dial, real rotational bearings. Built for your home garage.
4-Ton Capacity Per Plate
Each plate supports up to 4 tons of load, handling 8 tons combined when used as a pair. Die-cast metal construction handles passenger cars, trucks, and SUVs.
±60° Rotation Range
The rotating top plate sweeps a full ±60° left and right from centerline, giving you the range needed for caster sweeps without hitting stops or adapters.
Brass Dial, 1° Increments
An etched brass degree dial you can read from any angle. 1° graduations let you read and record angles during camber and caster adjustments.
1" Centerline Offset
The 13-3/8" rotating top plate includes a 1" slide tolerance from centerline. Accommodates lateral wheel travel during steering input so the tire can move naturally mid-sweep.
Smooth Rotational Bearings
Internal rotational bearings carry the plate weight smoothly under full load. Steering input moves through freely without binding, protecting your caster readings.
Locking Pin & Carry Handle
A built-in locking pin holds the plate at 0° for safe drive-on positioning. Integrated carry handles make moving and storing pairs straightforward.
15.75" × 15.75" Footprint
Compact, uniform dimensions fit standard pit racks and alignment setups. Each plate is lightweight enough for one-person setup in a home garage.
Two Profiles, One Standard
Pick ASWG004 (0.8" ultra-low) for flat-floor drive-on, or ASWG008 (1.9" raised) for pit racks and raised platforms. Both use the same brass dial, bearings, and centerline geometry.
Complete Kit. No Extras Needed.
Every pair ships with transition bridges for smooth drive-on access, wheel chocks for secure positioning, and a user manual. Integrates directly into the AutoSolo alignment system.
Add the rear level platforms.
The drive-on turn plates lift the front wheels. For string toe and thrust, the rear needs to sit at the same height. The ASRP004 adds four drive-on ramps and two rear leveling platforms, sized for the drive-on plates, so all four wheels sit level and the whole setup reads flat.
Tools you can rely on. Support you can reach.
Trusted by DIY Mechanics
Used by home garage enthusiasts, classic car builders, and hobby mechanics worldwide.
Tested in Real Garages
Reviewed by automotive creators and DIY alignment builders across YouTube and beyond.
Backed by U.S. Support
Fast help, product guidance, and friendly support from our U.S.-based team.
1-Year Replacement Support
If any manufacturing defects occur, our team will ship a replacement promptly.
HOW TURN PLATES WORK
Wheel alignment turn plates are the rotating platforms that allow a vehicle's front wheels to pivot freely during the alignment process, eliminating the floor friction that causes false toe and caster readings. AutoSolo turn plates are available in two versions: the Standard Design at approximately 2 inches in height, and the Low Profile Design at approximately 1 inch in height for vehicles with limited ground clearance. Both designs measure 15.75 by 15.75 inches per plate. Each plate independently supports 2 tons, for a combined capacity of 4 tons when used as a pair. The brass finish dial reads steering angle up to 60 degrees left or right from centerline, providing a clear steering angle reference during toe and caster adjustment. The 13.375-inch rotating top plate includes a 1-inch slide tolerance to accommodate wheel track variation across different vehicles. Each pair ships with two thrust blocks and two transition bridge ramps included at no additional cost.
User Manuals
Parts and Accessories
Verified owner reviews
What owners say
Ratings and reviews are supplied by Judge.me from verified purchases.
3 stars just because the turn plates are not very smooth, and the latches don’t stay in very well. But you get what you pay for, with that being said they are great for the cost
top
They work really well, I used them for my 3/4 ton pickup with a duramax diesel engine and they worked great even with all the extra weight. You will need to put a small ramp or couple pieces of thin wood to get up on them or they will slide, no biggie with me, I had some scrap plywood pieces that were perfect.
Great product. Fast shipping!
Eseguito convergenza "fai da te" con filo. Straordinario il risultato. Consiglio però di fissare le piastre su una tavola di legno in modo da avere un intramezzo tra piastra e pavimento.
Item as described
Very heavy duty, I can put large trucks on these without a problem.Understand you need to know what you are doing with these; they aren't magic.
Perfectos
Most alignment shops are not taking classic cars anymore. The shop I use for our daily driver cars only does vehicles after 1992. If you have classic cars as we do the alignment turntables are a must. They take a several hour job and make it possible in well less than an hour. Awesome product.
If you've never used these type of plates for alignments than there is a slight learning curve until you get “the feel" for it. If your mechanically inclined then a few seconds is all that's needed. Handy tool.
EXC
They are plastic!
Makes getting your front end aligned in your garage after front end repair easier. Sure you can use plastic bags or cardboard but this does work better if you plan on tinker for years.
It works well and was a great value for the money.
Muy bueno.
Work good for the money
reasonable price
Honestly, I should know better. these are plastic junk and will not hold up to repeated usage for a professional shop. They're cheap. For an amateur who want's to tinker with their own car at home or something where alignment isn't critical, they'll probably be fine.
All wasgreat
The blocks are too soft of material. Will not support a vehicle and deform by hand twisting. Turn plates operated well. Have not found a repair kit to replace the balls yet, hope I never need one.
Works like it's intended to. No issues
Great product. 2nd time I purchased
Price
Good
Received in a timely fashion
Good dyi product
These tables are lightweight and easy to use exactly what I wanted!
Thanks
Used with a Longacre gauge and worked .
The turn plates are a high quality and works very good. The built in degree indicator makes caster adjustment very easy. Very happy with the turn plates from Zackman Scientific
Great product! Works great!!
delivered in plain box undamaged/sturdy appearing /well made. that being said no paperwork for suggestions of use or set up . no website available to download information . apparently on your own ? no one to contact etc.we shall see --oh well!!!
